Krone Comprima V 180 - Setting the Brake Force Release When Feeding Wrapping Material

Settings 15
Setting the brake force release when feeding wrapping material 15.4
Comprima V 180
Original Operating Instructions 150001053_00_en 149
Checking and setting the bale formation conveyor tension at front
X
Y
2
1
3
RP000-490
The spring(3) has been correctly set when the dimension X=130mm and the dimension
Y=690mm.
When the double rocker arms(1) on the right and left sides of the machine are at the same
height, both springs(3) must have the same spring tension.
Make the following settings on the right and left sides of the machine in the same way:
ü The machine is shut down and safeguarded, refer to page25.
ü The stop(2) is in position(III) (low bale core density).
ü The double rocker arm(1) is positioned on the stop(2).
ü The bale chamber is closed.
 Set the spring(3) so that the dimensions X=130mm and Y=690mm.
15.4 Setting the brake force release when feeding wrapping material
1
3
2
4
RP000-019
Particularly when the chamber film wrapping is set, there is a risk that the film will overturn on
the film roll instead of being fed to the round bale. If this happens, the brake force release
should be adjusted for the feed process.
When the wrapping material is guided to the round bale, the brake force should be reduced so
that the wrapping material can be pulled more easily off the round bale.
This brake force release during the feed process can be set on the spring(3) on the right side of
the machine behind the side hood.
