Malfunction, cause and remedy 17
Setting the tailgate lock 17.6
Comprima V 180
Original Operating Instructions 150001053_00_en 225
2
1
5
4
3
RP000-532
It can be read off on the baling pressure indicators (4) on the right-hand side of the machine
whether the tailgate is fully closed. The tailgate is completely closed when the baling pressure
indicators(2) are lifted slightly off the stop (5) and the wire rope (3) is tensioned.
If the baling pressure indicators (4) are lifted considerably off the stop (5), the tailgate no longer
closes fully.
Make the following setting on the right and left sides of the machine in the same way:
 Check that the tailgate lock is set correctly, refer to page224.
 To set the baling pressure indicators, release the screw connection (2) on the rope pulley (1)
and push in the oblong hole so that the wire rope (3) is tensioned.
