6 Initial operation
6.1 Scope of delivery
44
Comprima V 180
Original Operating Instructions 150001053_00_en
14.1 14.2 14.3
14.4
14.8
14.7
14.6
14.5
14
12
5
1
2
9
10
7
8
4
6
3
11
13
RPG000-056
1 Protective cap 12 Universal shaft bracket
2 Universal shaft 13 Spanner for reversing device
3 Ring spanner 14 Bale ejector components
4 Terminal (depending on version) 14.1 Bale ejector
5 Small parts 14.2 Linkage
6 7-pin connection cable for road travel
lighting
14.3 Eye bolts
7 Hose and cable support 14.4 Springs
8 Mounting material 14.5 Strips
9 Can of spray paint 14.6 Screws
10 Warning foil 14.7 Springs with clamping screws
11 Test roll KRONE excellent, net for net
wrapping
14.8 Spacer
