12-22
Appendix > Specifications
*1 Up to upper limit height line in the cassette.
*2 This is standard in Inch Model.
*3 Use slot 2 for FAX system.
Image Write System Semiconductor laser and electrophotography
Memory Standard: 1536MB(1.5GB), Maximum: 3072MB(3.0GB)
Interface Standard USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1 (1000Base-T/100Base-TX/10BASE-T [IPv6IPv4IPSec], 802.3az
supported)
USB Host: 2 (Hi-Speed USB, USB memory slot)
Wireless LAN (Option): 1 (For IB-36 mounting)
*2
Option eKUIO: 2
(For HD-6/HD-7/FAX System*3/IB-50/IB-51 mounting.)
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80 %
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H)
(without Document Processor)
23.23" × 23.23" × 29.65"
590 × 590 × 753 mm
Weight ECOSYS M8124cidn: Approx. 169.8 lb/Approx. 77 kg (without toner container)
ECOSYS M8130cidn: Approx. 174.2 lb/Approx. 79 kg (without toner container)
Space Required (W × D)
(Using multi purpose tray)
34.37" × 23.23"
873 × 590 mm
Power Source 120 V Specification Model: 120 V 60 Hz, 7.2 A
220 V -240 V Specification Model: 220 to 240 V 50 Hz, 3.5 A
The power consumption of the
product in networked standby (If
all network ports are connected.)
The information is available at the website below.
http://www.kyoceradocumentsolutions.eu/index/environment/
green_products/low_power_consumption.html
Options
Optional Equipment (12-2)
Item Description
To Next Page
