Table 10. 3 DDL Keyword Definitions and Valid Values
Keyword Valid Values Description
Device 16 character text string Defines the name of the device.
Trai t 8 character text string Defines the text label of the trait.
Type Union, End Union,
Continuous, Indexed
Defines the type of the trait.
Channel 1 - 256 Defines the channel offset of the trait.
Size 8 Bit, l6 Bit Defines the trait as 8 bit or 16 bit. Only used
in continuous types.
Invert Yes, No Causes the trackball to work opposite of
normal when controlling the trait.
X-axis Yes, No Assigns the trait to the horizontal movement
of the trackball.
Y-axis Yes, No Assigns the trait to the vertical movement of
the trackball.
Black Yes, No Assigns the trait to the Blackout key.
Index 8 character text string
followed by a comma
and a value ranging
from 0 - 255.
Defines the text label and its value of an
index entry of an indexed type trait.
End None Defines the end of the file.
BoValue 8 Bit : 0 - 255
16 Bit: 0 - 65,535
Defines the value that the Blackout button
assigns to the trait.
Master Yes, No Assigns the trait to the Grandmaster
Default 8 Bit : 0 - 255
16 Bit: 0 - 65,535
Defines the value that the Default key
assigns to the trait.
Maximum 8 Bit : 0 - 255
16 Bit: 0 - 65,535
Defines the maximum value of a continuous
trait.
Minimum 8 Bit : 0 - 255
16 Bit: 0 - 65,535
Defines the minimum value of a continuous
trait.
