Assembly 42: Electrical 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9207 1 1 Engine controller board
“Engine controller board removal” on
page 353
2 40X9744 1 1 Engine controller board FFC --
3 40X9210 1 1 ADF/scanner image
controller board
“ADF/scanner image controller board
removal” on page 354
4 40X9663 1 1 Controller board (MFP)
“Controller board removal” on page 356
5 40X9209 1 1 Controller board fan
“Controller board fan removal” on
page 366
7421
Parts catalog
626
