Assembly 57: ADF paper transport 6
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9685 1 1 ADF transport gear --
2 40X9953 1 1 ADF exit roller --
3 40X9695 1 1 CIS glass clean motor cable --
4 40X9691 1 1 ADF glass clean encoder belt --
5 40X9213 1 1 Motor (CIS glass clean)
“Motor (CIS glass clean) removal” on
page 439
6 40X9214 1 1 CIS glass clean belt --
7 40X9693 1 1 CIS glass clean gear --
8 40X9694 1 1 ADF glass clean encoder --
7421
Parts catalog
656
