Operating elements for driving
3.2 Short description of the operating elements
3 - 44 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
3.2.4 AdBlue system
Instrument panel
AdBlue warning
Torque reduction indicator lamp
Override torque reduction
AdBlue level display
–Go out: Filling level sufficient, no fault
– Lit: AdBlue system malfunction
– Flashing: Adblue tank empty or fault
à p. 5 - 45
–Go out: Torque reduction off
– Lit: Torque reduction on
– Flashing: Reduction in torque on the next time the engine is
started
à p. 5 - 45
– Press upwards once: Torque reduction overridden for 30 minutes
after 30 minutes
– Press up again: Torque reduction overridden for 30 minutes
after 30 minutes
– Press up again: Torque reduction overridden for 30 minutes
à p. 5 - 45
Shows the current Adblue filling level when the ignition is switched on
à p. 5 - 45
