Rigging work
12.5 Starting the engine for rigging
Operating manual 3 302 736 en 12 - 27
GMK4090
xx.xx.xxxx
12.5 Starting the engine for rigging
For rigging work, you can start the engine:
– With the hand-held control
– From the control units of the outriggers.
H
You can generally start the engine only if a bridging plug is inserted in all
sockets not required.
12.5.1 Starting/shutoff the engine – with the hand-held control
Prerequisites The following requirements must be met before you can start the engine for
driving with the hand-held control:
– The ignition is switched off in the crane cab.
– The ignition is switched off in the driver's cab.
• Connect the hand-held control to a socket; à p. 12 - 25.
s
G
Risk of crushing due to turning wheels
When you start the engine, no persons may be within the steering range of
the 3rd and 4th axle lines. These axle lines can be briefly steered during the
start of the engine; sometimes with five seconds delay.
