Driving
5.1 Before driving
Operating manual 3 302 736 en 5 - 13
GMK4090
xx.xx.xxxx
5.1.3 Adjusting the seat and the steering column
Adjusting the
driver's seat
The seat height and lumbar support are adjusted pneumatically. You can
only make these adjustments when:
– the switch (1) on the driver's seat is switched off (not pressed in),
– sufficient air pressure is available in the secondary consumer circuit. You
may have to build up the supply pressure;
à p. 5 - 10.
• Sit on the driver's seat; the seat will rise to the last position set.
You can make adjustments to suit your body size and shape.
Settings for body size
s
1 Back rest – angle
2 Seat heating on/off
1)
3 Lower it to the lowest position
4 Seat – height
5 Seat – inclination
6 Spring hardness
7 Seat longitudinal adjustment
8 Seat cushion – longitudinal adjustment
9 Armrests – inclination
1)
1)
Additional equipment
