Operating elements for driving
3.2 Short description of the operating elements
Operating manual 3 302 736 en 3 - 49
GMK4090
xx.xx.xxxx
Selecting / deselecting favourites
Several symbols can be selected as favourites. The cursor jumps directly
from favourite to favourite when scrolling through the menu groups.
Select
A symbol is selected, such as symbol (2).
Deselect
A favourites symbol is selected.
3.2.8 Transmission
à Operating the transmission, p. 5 - 25.
Transmission
control unit
Selecting the transmission mode
The engine must be running.
s
1Press
The symbol is marked as a favourite.
1Press
The favourites selection is cancelled.
– Position N: Select neutral – no gear engaged
– Position D: When at a standstill – Select forwards starting gear
When driving forwards – Select a suitable gear,
clutch engages
When driving in reverse – Select neutral
