Rigging work
12.11 Other rigging work
12 - 152 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
12.11.2 Open/close coverings at the turntable
Opening
• Open the locking bar and lift the
coverings (1) upwards out of the stowing
bracket.
You can attach the coverings (1) during
maintenance work into the stowing
brackets (2).
Closing
• Lift the coverings (1) out of the stowing
bracket (2) and close it.
• Allow the locking bar to engage audibly.
