Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual 3 302 736 en 9 - 107
GMK4090
xx.xx.xxxx
9.2.11 Outrigger pressure displays
Outriggers
submenu
Outrigger pressure display
Outriggers control
units
Outrigger pressure display
9.2.12 Anemometer displays
This function is the same in all the menus.
The anemometer is electrically connected.
v
max
= maximum permissible/reduced wind speed as shown in the Lifting
capacity table
– Unit of
measurement:
Displayed depending on setting
– t – tons or
– klbs – kilopounds – (1 kilopound = 1,000 lbs)
– Precision: One decimal place
à p. 12 - 68
– Unit of
measurement:
Lights up depending on setting
– t – tons or
– klbs – kilopounds – (1 kilopound = 1,000 lbs)
– Precision: When in t, one place of decimals
When in klbs, no places of decimals
à p. 12 - 69
1 Display in metres per second (m/sec) or Beaufort scale (B)
2 Variable measurement range – 100% = v
max
–Green: Display (1)  90% of v
max
–Red: Display (1) > 90% of v
max
à p. 11 - 72
