Driving
5.1 Before driving
Operating manual 3 302 736 en 5 - 1
GMK4090
xx.xx.xxxx
5 Driving
5.1 Before driving
5.1.1 CHECKLIST: Checks before on-road driving
H
This checklist is not a complete operating manual. There are accompanying
operating instructions which are indicated by cross-references.
Observe the warnings and safety instructions specified here
1. For on-road driving without a dolly
– Depending on the driving mode, the counterweight must be
unrigged;
à p. 6 - 1, à p. 12 - 71.
– The main boom must be telescoped for driving operation;
à p. 11 - 108.
– All telescopic sections must be locked together.
– The slewing gear is switched off;
à p. 11 - 118.
– The boom must be resting in the boom rest.
– The boom must be resting in the boom rest.
If the
Vehicle height monitoring function is present, then the symbol for
the
Main boom not set down warning is hidden.
s
