Malfunctions in driving mode
8.3 Warning and error messages
Operating manual 3 302 736 en 8 - 13
GMK4090
xx.xx.xxxx
8.3.3 Warning messages on the CCS display
A warning message indicates that certain val-
ues do not correspond to a target value
If CCS detects a warning or a fault then in the
display area (1) a symbol is displayed.
Meaning of the symbols
The colour of the symbols indicates whether a warning or malfunction mes-
sage is active in the corresponding area.
– Symbol yellow – malfunction.
– Symbol red – warning message.
– no symbol – no malfunction or warning message.
If a symbol is displayed in red or yellow, perform the following checks.
Symbols in the
display area
Voltage monitoring
The voltage in the electrical system is too high or too low.
Display of the current voltage;
à p. 4 - 18.
s
S
Risk of damage if warning messages are disregarded
Observe the following information in good time and take the appropriate
remedial measures if a warning message appears. This prevents these mal-
functions causing defects in the truck crane.
