Rigging work
12.10 Rigging work on the main boom
12 - 132 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
12.10.6 Rigging aid for the hoist rope
Depending on the version, a rigging aid for the hoist rope is provided with
the auxiliary hoist.
Scope of delivery
Making the connection
• Place the end of the hoist rope (1) in part (2)
of the connector.
• Screw part (2) and (3) of the connector
together.
• Attach the rope (4) to the connector.
1 Connector, two parts
2 Rope
S
Risk of damage to the hoist rope
Always rig the hoist rope with the rigging aid. This prevents slack rope.
Rope loops will form, which can cause the load to slip and damage the hoist
rope.
