Operating elements for driving
3.2 Short description of the operating elements
3 - 64 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
3.2.16 Lighting/windscreen wipers/horn
Steering column Multipurpose switch
Headlight flasher/headlight – full beam
Turn signal indicator/wiper-washing system
Steering wheel
Horn
The ignition is switched on
Instrument panel
Checking headlight – full beam
1 Parking light/headlight: Middle position
2 Flash the headlights: Upwards
The parking light/headlight must be switched on:
3 Headlight – full-beam: Down – latches into place
4 Right turn signal indicator: Forwards
5 Left turn signal indicator: Backwards
6 Windscreen wiper/washing sys-
tem:
Press
7 Windscreen wiper: rotate:
–Off
– Interval – slow
– Interval – fast
– Continuous wiping – slow
– Continuous wiping – fast
–Press: Carrier horn on
1 – Lights up: Headlight – full beam on
–Go out: Headlight – full beam off
2 – Lights up Headlight flash
