Crane operation
11.1 Before operating the crane
11 - 8 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
11.1.3 Adjusting the crane cab seat and front control panel
Crane cab seat You can adjust the crane cab seat to your height.
Version 1
Version 2
1 Control panel right – height
2 Control panel left – height
3 Back rest – angle
4 Seat – height
5 Seat – longitudinal adjustment
with control panels
6 Seat – longitudinal adjustment
without control panels
7 Seat cushion – angle
1 Control panel right – height
2 Control panel left – height
3 Back rest – angle
4 Seat heating
1)
on/off
5 Seat – height
1)
6 Seat – longitudinal adjustment
with control panels
7 Adjust suspension stiffness to body
weight
8 Seat – longitudinal adjustment
without control panels
9 Seat cushion – angle
10 Upper lumbar area support
11 Lower lumbar area support
1)
Requirement – ignition is on
