Driving modes
6.4 Installing/removing the outrigger beams
6 - 32 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
6.4.12 Transporting the outrigger beams
•
For transportation, be sure to use a separate vehicle with sufficient load
bearing capacity. Transport dimensions and weight;
à p. 1 - 10.
• Load the separate vehicle in such a way that the weight is evenly distrib-
uted.
• Load the outrigger beam so that it that does not endanger other traffic.
When the outrigger pads are mounted
• Place the outrigger beam onto a suitable fixture (1).
• Secure the outrigger beam from slipping.
When the outrigger pads are dismounted
• Lay the outrigger beam onto the side.
• Secure the outrigger beam from slipping.
• Lay the outrigger pads onto the separate vehicle and secure them for
transportation.
6.4.13 Note on error messages with removed outrigger beams
When the outrigger beams have been removed, speial error messages
appear on the
CCS display. The error messages indicate only that the elec-
trical connection between the outrigger beams and the crane control is dis-
connected. Overview of the error messages;
à Special error messages,
p. 8 - 18.
S
Risk of damage to the outrigger beams and outrigger pads!
When outrigger pads are mounted, always use a device to set them down.
If you lay the outrigger beams onto the side, connections may tilt and
become damaged.
