Operating elements for driving
3.2 Short description of the operating elements
3 - 70 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
3.2.19 Diagnostics
The diagnostics connections may only be operated by service staff from the
engine manufacturer/transmission manufacturer, or by
Manitowoc Crane
Care
.
The following connections are below the
cover (4)
.
3.2.20 Push-up roof
Opening
Hold the push-up roof (1) by the handles (2)
and push up into the required position.
Closing
Hold the push-up roof by the handles (2) and
pull down until it latches into place.
1 Engine/Transmission diagnostics
2 Carrier electronics diagnostics
