Operating elements for driving
3.2 Short description of the operating elements
3 - 50 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Gearshift lever
– Position R: When at a standstill – Select reverse starting gear
When driving in reverse – No gear change
When driving forwards – Select neutral
The truck crane may be stationary or driving.
– Press in once: Change over between
automatic and manual oper-
ating mode – without change of gear
à p. 5 - 29
The truck crane must be stationary.
– Push forwards once: Upshift starting gear – 1 gear
– Push to the rear
once:
Downshift starting gear – 1 gear
The truck crane moves.
– Push forwards once: Upshift – 1 gear
Manual operating mode on
– Push to the rear
once:
Downshift – 1 gear
Manual operating mode on
à p. 5 - 32
