Operating elements for driving
3.2 Short description of the operating elements
3 - 60 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Steering system warning
Separate manual steering
The separate manual steering must be switched on.
1. and 2nd axle lines are steered with the steering wheel.
Press and hold button (1)
1 After switching on the ignition
– Lit – goes out after about three seconds if there is no error
Whilst driving
– Lit – symbol (2) red
Steering system faulty!
3. axle cannot be steered
Stopping while taking the traffic situation into account
Repair required
à p. 8 - 7
– To the left: 3. and 4th axle lines – turn to the left
– To the right: 3. and 4th axle lines – turn to the right
à p. 5 - 61
