Operating elements for driving
3.2 Short description of the operating elements
3 - 66 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Checking headlight
Rotating beacon on/off
CCS display
Outrigger lighting on/off
Roof The lamps on the driver's and passenger's side are identical.
Cab lighting
–Lit: Headlight on
– Go out: Headlight off
– Switch on: Push up
– Switch off: Push down
– Switch on: Select and confirm symbol (2)
– Switch off: Select and confirm symbol (1)
1On
2 On/off via door contact
3Off
4 Reading lamp on
