Driving modes
6.1 Driving modes
Operating manual 3 302 736 en 6 - 5
GMK4090
xx.xx.xxxx
Tyres
525/80 R25
Also be aware of the effects on the axle loads when towing a trailer;
.
à p. 5 - 81
x
Driving modes
123456
Equipment
525/80 R25 tyres
✔ ✔ ✔✔✔✔
Drive 8 x 6 x 8
✔✔ ✔
Drive 8 x 8 x 8
✔✔ ✔
Steel rims
✔✔✔
Aluminium rims
✔✔✔
Retarder
✔ ✔ ✔✔✔✔
Auxiliary hoist or 0.5 t counterweight installed
✔ ✔ ✔✔✔✔
Rear bumper
✔ ✔ ✔✔✔✔
Rigging mode
385/95 R25 spare wheel on rear
Outrigger pad from steel ●●●● ●
Plastic outrigger pad ●
5.2 t counterweight attached to the turntable ●●●●
4.0 t counterweight attached to the turntable ●●
4.5 t counterweight on the counterweight platform
2.2 t counterweight on the counterweight platform ●●●
1.1 t counterweight on the counterweight platform ●●●
Storage compartment on the rear with a capacity of 500
kg
●
Hook tackle hung on the bumper
1)
1- sheave hook block attached to the bumper
1)
●
3- sheave hook block attached to the bumper
1)
●●●● ●
Add-on parts for lattice extension installed
2)
●●●
Hose drum for lattice extension installed
2)
●●●
Lattice extension, hydraulic, laterally folded ●●●
AP switch cabinet with diesel generator or narrow stor-
age compartment
●
1)
The weight of the hook blocks is based on the information in this oper-
ating manual.
2)
All driving modes also apply to the crane without add-on parts and
without a hose drum.
