Malfunctions in driving mode
8.7 Fuses on the carrier
8 - 54 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Designation
Amper-
age (A)
Function
F8/1 5 Central lubrication
F8/2 15 Windscreen wiper
F8/3 5 Steering coupling
F8/4 3
ABS
ABS trailer
F8/5 10 Horn
F8/6 15 Unassigned
F8/7 10
Operating the mirror adjustment
Window winder
F8/8 - Unassigned
Designation
Amper-
age (A)
Function
F9/1 2
Temperature gauge
Fuel gauge
F9/2 - Unassigned
F9/3 Unassigned
F9/4 - Unassigned
F9/5 - Unassigned
F9/6 - Unassigned
F9/7 - Unassigned
F9/8 - Unassigned
