Operating elements for crane operation
9.1 Overview of the operating elements
Operating manual 3 302 736 en 9 - 61
GMK4090
xx.xx.xxxx
Telescoping
emergency
program menu
s
XXX sec
XXXX mm
#1
#2
XXXX mm
1 Input access code emergency program
à p. 14 - 31
2 Remaining time emergency program display
3 Telescoping cylinder length display
4 Proximity switch display
5 Locking status telescoping cylinder display
6 Symbol lock/release telescoping cylinder
7 Locking status telescopic section display
8 Symbol lock/release telescopic section
