Operating elements for crane operation
9.2 Short description of the operating elements
9 - 142 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
RCL override –
version B
This point only applies to RCL programming deviating from EN 13000. For
RCL programming in accordance with EN 13000;
à p. 9 - 141.
Overriding the RCL in an emergency
No function
No function
1 – Press once:
RCL shutdown overridden – crane functions
enabled
– Crane functions can be started within the next
10 seconds.
– Speed of movements increasing load moment
max. 15%.
à RCL override – version B, p. 11 - 65
