Manitowoc GROVE GMK4090 User Manual

Overview
1.5 Technical data
1 - 14 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Counterweight
parts
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Auxiliary hoist
Description
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
0,5 t counterweight section 0.48 x 1.28 x 0.15
(1.57 x 4.19 x 0.49)
500
(1,102)
1,1 t base plate 1.19 x 2.53 x 0.75
(3.90 x 8.30 x 2.46)
1,100
(2,425)
1,15 t counterweight section 1.19 x 2.53 x 0.13
(3.90 x 8.30 x 0.43)
1,150
(2,535)
4,6 t counterweight section 1.19 x 2.53 x 0.37
(3.90 x 8.30 x 1.21
4,600
(10,141)
2,3 t counterweight section 1.19 x 2.53 x 0.20
(3.90 x 8.30 x 0.66
2,300
(5,070)
2,9 t counterweight section 1.19 x 2.53 x 0.18
(3.90 x 8.30 x 0.59
2,900
(6,393)
1)
There may be deviations of up to  3% due to the manufacturing pro-
cedure.
Description
Length x width x height
in m (ft)
Weight
in kg (lbs)
Complete auxiliary hoist 0.67 x 0.98 x 0.56
(2.19 x 3.21 x 1.84)
830
(1,830)
