Overview
1.5 Technical data
1 - 18 3 302 736 en Operating manual
GMK4090
xx.xx.xxxx
Electrical system
Tool 1 tool kit in tool box,
wheel chocks (number according to national regulations)
Towing couplings
Driving speeds At an engine speed of 1,700 rpm
Climbing ability Transport weight 48 t (105,822 lbs)
Alternator: 28 V/100 A
Batteries: 2 each of 12 V/180 Ah
Voltage: 24 V
Front towing coupling: 100 kN (22,480 lbf) permissible tension
1)
Rear tow lug: 75 kN (16,860 lbf) permissible tension
1)
1)
Only permissible at certain tension angles; Ã p. 5 - 58
Forwards: max. 80.0 km/h (49.7 mph)
Reverse: about 6 km/h (3.7 mph) depending on the tyres
Drive
Climbing ability with tyres
385/95 R25 445/95 R25 525/80 R25
8 x 6 x 8 44% 42% 42%
8 x 8 x 8 47% 43% 43%
