Powering the MASSO Touch

The MASSO Touch power supply connector is located at the top-right corner of the controller as seen in the

picture below. MASSO Touch requires a power supply of 24 VDC with a minimum of 1.5 Amps output.

MASSO Touch will power on instantly once power is connected.

v5.18 - 08 Apr,2021

www.masso.com.au Page 37 of 477
