About the Patching screen 73
PRO Series Live Audio Systems
Owner’s Manual
>> To access the Patching screen
Do one of the following:
• At the GUI, choose homePatching.
• Press the patching/metering button in the primary navigation zone.
• At the GUI, click a src (source) or dest (destination) button. The Patching screen
will open at the appropriate tab/configuration window.
7 RESTORE button Reverts patching status to the last checkpoint or, if no
checkpoints have been created, it will revert patching
status to the power up condition. All patching done in
the intervening period will be lost.
8 UNDO button Undoes the latest single patch, even if it was part of a
multiple patching operation. Repeated clicks will
undo the preceding patching operations, going back
to the last checkpoint, or power up if no checkpoints
have been created.
9 REDO button Redoes an undo. This can be repeated for each undo
in the previous undo operation.
10 CLEAR SEL.
button
Clears all current selections and their patches.
Important:
Unlike the NONE button, which merely removes
the current selections (highlighted in yellow),
CLEAR SEL. goes a step further by removing the
patch as well. This will stop any audio that may
have been going through the patched signal.
11 CLEAR button Clears all patching (see “To clear all current patching”
on page 98).
Important:
Exercise great caution when using this function.
Observe the warning that appears after clicking
this button.
12 CONFIG button Opens the AES50 Device Configuration window,
from where you can set up the I/O tabs in the
Patching screen (see “Typical AES50 Device
Configuration window” on page 92).
13 STORE PRESET
and LOAD
PRESET buttons
These are user library (preset) function buttons (see
Chapter 24 "User Libraries (Presets)" on page 235).
14 Title section Section titles and tab names.
15 Patching area Contains all of the patch connectors on tabs.
16 To section Houses the tabs that contain all of the patch
connector destinations (see Table 4 “Patching screen
tabs” on page 75).
17 From section Houses the tabs that contain all of the patch
connector sources (see Table 4 “Patching screen tabs”
on page 75).
Item Element Description
