Mixes 305
PRO Series Live Audio Systems
Owner’s Manual
After selecting a bus, control is via one of the following methods:
Once the bus mix controls have been selected, they offer rotary control of relative
contribution levels onto the buses operating as shown in the following table.
Table 19: Function of mix control knobs
Bus type Control
Mono aux/matrix Level from fader; ON and PRE active
Stereo aux/matrix Level from fader; pan from main pan; ON and PRE
active
Stereo aux/matrix Level from fader; pan from main pan; ON and PRE
active
Mono group Post-main fader; ON active
Stereo group Post-main fader and pan; ON active
Mono mix minus Post-main fader; ON means ‘minussed’ from the bus
Stereo mix minus Post-main fader and pan; ON means ‘minussed’ from
the bus
Bus type
level/pan
control knob
function
level control
knob function Description
Mono Level Level Independent left and right level
adjustments (both +6dB to OFF).
With ON and PRE switching (plus
LED indication).
Stereo Pan Level Pan adjustment is constant power
law at -3dB. Level adjustment is
continuous (+6dB to OFF). With
ON and PRE switching (plus LED
indication).
Subgroup N/A N/A Both levels are disabled. 0dB only
for group buses, mix and main
buses. With ON switching (plus
LED indication).
