Midas PRO SERIES User Manual

324 Chapter 31: Outputs
PRO Series Live Audio Systems
Owner’s Manual
3 Click GEQ. in the processing area.
4 Click a non-control area of the GEQ image (shown
right) to open the GEQ window.
>> To close the GEQ window
In the GEQ window, click CLOSE.
Navigating the PEQ output bands
You can change band selection by
clicking the UP/DOWN buttons in the EQ
processing area. This will change
selection by one band at a time.
Yellow rectangle
shows which four
bands are currently
displayed. Bands are
shown in descending
order from top to
bottom (Band 6 is
top).
Band navigation
buttons

Midas PRO SERIES Specifications

General

Series	PRO SERIES
Sample Rate	96 kHz
Word Clock	Yes
Type	Digital Mixing Console
Mix Buses	Up to 24
Connectivity	AES50
Control Surface	Motorized Faders
EQ Bands	4-band Parametric EQ per channel
Effects	Multiple internal effects engines
Frequency Response	20 Hz - 20 kHz
Processing	40-bit floating point
