16 Chapter 2: PRO Series Live Audio Systems
PRO Series Live Audio Systems
Owner’s Manual
Table 3: Standard equipment supply per PRO Series system
Item PRO3 PRO6 PRO9
Control centre Thee slots in rear
panel populated with:
DL443 module and
two blank panels.
Thee slots in rear
panel populated with
the following
modules: DL442,
DL443 and DL452
Thee slots in rear
panel populated with
the following
modules: DL442,
DL443 and DL444
Control centre
supplied in ...
Shipping crate Flight case Flight case
DL251 Audio System
I/O
Yes No No
DL351 Modular I/O No Populated with seven
DL441 analogue input
modules (56 main
inputs) and a DL442
analogue output
module. There are a
total of 56-off XLR
mic/line inputs
provided on the
system.
Populated with seven
DL441 analogue input
modules (56 main
inputs) and a DL442
analogue output
module
DL371 Audio System
Engine
Populated with five
cards, the two empty
slots being blanked
off. (If the optional
N+1 redundant DSP
module card is fitted,
there will be six cards
and one empty slot.)
Populated with five
cards, the two empty
slots being blanked
off. (If the optional
N+1 redundant DSP
module card is fitted,
there will be six cards
and one empty slot.)
Populated with five
cards, the two empty
slots being blanked
off. (If the optional
N+1 redundant DSP
module card is fitted,
there will be six cards
and one empty slot.)
DL431 Mic Splitter No No No
DL451 Modular I/O No No Populated with 3-off
DL441 input modules
DL441 analogue input
(mic) module
No 7-off in DL351 7-off in DL351,
3-off in DL451
DL442 analogue
output module
No 1-off in DL351,
1-off in PRO6 Control
Centre
1-off in DL351,
1-off in PRO9 Control
Centre
DL443 analogue Jack
I/O module
1-off in PRO3 Control
Centre
1-off in PRO6 Control
Centre
1-off in PRO9 Control
Centre
DL444 8 analogue mic
in and 8 analogue line
out module
No No 1-off in PRO9 Control
Centre
DL452 AES/EBU input
and output module
No 1-off in PRO6 Control
Centre
No
Rack units supplied
in ...
14U rack, in a flight
case
16U rack, in a flight
case (packing may
vary by territory)
16U rack, in a flight
case (packing may
vary by territory)
Interconnecting
(N+1) rack Cat 5e
copper cable
4-off 4-off 4-off

Midas PRO SERIES Specifications

General

Series	PRO SERIES
Sample Rate	96 kHz
Word Clock	Yes
Type	Digital Mixing Console
Mix Buses	Up to 24
Connectivity	AES50
Control Surface	Motorized Faders
EQ Bands	4-band Parametric EQ per channel
Effects	Multiple internal effects engines
Frequency Response	20 Hz - 20 kHz
Processing	40-bit floating point
