6.2.1 Head Assy
1
2
3
4
5
6
7
8
8. Remove the GEN Head Holder (imetal plate) from the Head
Assy.
Screw : B3x6 x2
9. Perform the assembly by reversing the disassembly procedure.
Head Assy
GEN Head Holder
Maintenance Manual > Disassembly and Reassembly > Ink-related Parts > Head Assy
Model UJF-3042/FX Issued 2010.08.27 Revised 2011.09.30 F/W ver --- Remark
2.0
