© 2011 MIMAKI ENGINEERING CO.,LTD. 6.5.1 R.2.0 P.2
6.5.1 X origin sensor
1
2
3
4
5
6
7
8
5. Take the Sensor off.
Remove Fixng screw.
Disconnect the connecter of the sensor.
6. Perform the assembly by reversing the disassembly procedure.
Maintenance Manual > Disassembly and Reassembly > Sensors > X origin sensor
Model UJF-3042/FX Issued 2010.08.27 Revised 2011.09.30 F/W ver --- Remark
2.0
Rev.
