Minebea Intec PR5900 - Page 161

Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Interface] .
WP-D Max -------?? d= -------??
no values from scale
Weighing points @admin
Weighing point A
Weighing point B
Weighing point C
Weighing point D
Internal weighing point
Pendeo Truck
xBPI scale
SBI scale
Parameters
Weighing point D @admin
Weighing point
Interface
Baudrate
Data bits
Parity
Stop bits
SBI scale
Built-in RS-485
9600 baud
8 data bits
odd parity
1 stop bit
Default Save
[Interface]
Serial interfaces.
Selection: not assigned, Built-in RS-232, Built-in RS-485,Option‑x RS-485‑A,
Option‑x RS-485‑B
[Baud rate]
Baud rate of the data transfer.
Note:
The selected value must match the value of the connected device.
Selection: 300, 600, 1200, 2400, 4800, [9600], 19200 baud
[Data bits]
Groups of data bits.
Selection: 7 data bits, [8 data bits]
1. In this case: Select and conrm [Weighing point D] with [SBI scale].
A selection window opens.
2. Select and conrm the individual parameters.
