Note:
The menu item [Modify] is only used for minor changes (e.g. changing the dead
load/preload). Otherwise, the menu item [New] should be selected.
WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
0.000 t
10000 d
1 d
New Modify
?
Corner correction will be reset.
Yes No
WP-D Max 400t d= 0.05t
70.000+ t
Calibration @admin
Number of platforms
Local gravity
Max
Scale interval
Dead load
Calibration weight platform 1
Calibration weight platform 2
2
9.81379 m/s²
400.000 t
0.050 t
8000 d
1 d
Platform 1 Platform 2 Save
Note:
The parameter [Number of platforms] only appears with 8 load cells. In this case:
Example for 2 platforms.
A prompt window appears.
2. Press the [Yes] soft key.
3. Select and conrm [Number of platforms].
