4.7.7.3.4.1 New
In this menu item (under Calibrate the scale), a new calibration of the digital weighbridge
load cell Pendeo
®
Truck is performed and congured.
Example data:
- Maximum capacity of a load cell: E
max
= 50 t
- Number of load cells: 4
- Max: 200.000 t
- Scale interval: 0.020 t
- Dead load: Empty weight
- Calibration weight: 11.000 t
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [Calib] - [Calibrate the scale] - [New] .
WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
0.000 t
10000 d
1 d
New Modify
The data from the last calibration is displayed.
WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
0.000 t
10000 d
1 d
New Modify
- The [New] soft key starts a new calibration, see Chapter 4.7.7.3.4.1.
- The [Modify] soft key (only use for minor changes!) changes an existing
calibration, see Chapter 4.7.7.3.4.2.
1. Press the [New] soft key.
