To use the empty scale (deck installed on a vehicle scale, no load) as dead load
(normal case):
WP-D Max 200t d= 0.02t
7.520+ t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
10000 d
1 d
Platform 1 by load by value Save
Note:
Once the dead load is known, the value can be overwritten by pressing the [by
value] soft key.
WP-D Max 200t d= 0.02t
0.000 t
Calibration @admin
Local gravity
Max
Scale interval
Dead load
Calibration weight
Corner correction
9.81379 m/s²
200.000 t
0.020 t
7.510 t
10000 d
1 d
Platform 1 Save
The conrmation is displayed with "setting scale interval…"
10. Do not load scale.
11. Select [Dead load] and press the [by load] soft key.
12. Conrm the entries.
The conrmation is displayed with "Setting dead load…"
13. Select and conrm [Calibration weight].
An input window opens.
