8.8.6 Configuring DNP3 (optional)
If you would like to use the DNP3 control system protocol, you must set the
parameters listed below. Also refer to the section Configuring the network
[►Section 8.3, Page 92] if you want to use the DNP3 via TCP.
Settings
Parameters
DNP3
Name Value
DNP3 transmission type TCP
TCP port 20000
Device address 1
Timeout for response confirmation 5s
Unsolicited messages Off
Destination address 10000
Timeout confirmation 5s
Indefinite unsolicited retries Off
Number of unsolicited retries 3
User ID code ISM
Reference time UTC
Home
Events
Information
Recorder
Settings
EN
CHANGE
REBOOT
admin 31.01.2020 13:05
Figure86: DNP3
1. Go to Settings > Parameters > System > DNP3.
2. Select the desired parameter.
3. Set the parameter.
4. Press the Accept button to save the modified parameter.
8.8.6.1 DNP3 transmission type
You can use this parameter to set the transmission type. You can select the
following options:
▪ TCP
▪ Serial
TCP port
You can use this parameter to set the TCP port.
Serial interface
You can use this parameter to select the serial interface for data transmis-
sion. You can select the following options:
▪ RS232
▪ RS485
