8 Operation
Maschinenfabrik Reinhausen GmbH 2020256 3587317/21 ENTAPCON
®
8.30 TAPCON® Personal Logic Editor (TPLE)
You can use the TAPCON® Personal Logic Editor (TPLE) function to pro-
gram simple logical links via the web-based visualization. You can also link
the inputs and outputs available on the device using function modules.
Note that the device does not meet the requirements of a protective device.
Therefore, do not use TPLE to produce protective functions.
8.30.1 Function
8.30.1.1 Function groups
There are 10 function groups available that you can use to combine various
sub-tasks into one function. In one function group, you can link up to 12
function modules with variables. You can rename function groups and acti-
vate or deactivate them individually.
8.30.1.2 Variables
The following types of variables for information processing are available for
TPLE:
▪ Event inputs: You can use all the device's events as inputs for a function.
▪ Event outputs: 100 generic events are available as outputs for functions.
▪ Binary inputs: You can use all the device's configured digital inputs and up
to 42 generic inputs of the device as inputs for a function.
▪ Binary outputs: You can use all the device's configured digital outputs and
up to 20 generic outputs of the device as outputs for a function. If there is
a control system present, 10 generic control system messages are avail-
able.
▪ Analog inputs: You can use all the device's configured analog inputs as in-
puts for a function.
▪ Binary flags: You can use up to 100 binary flags as variables to store in-
termediate values. You can use binary flags as inputs and outputs for a
function.
▪ Analog flags: You can use up to 50 analog flags as variables to store in-
termediate values. You can use analog flags as inputs and outputs for a
function.
▪ Discrete inputs: You can use all the device's available discrete inputs as
inputs for a function.
8.30.1.3 Function modules
TPLE provides various function modules for processing the information.
