12 Uninstallation
Maschinenfabrik Reinhausen GmbH 2020 2933587317/21 EN TAPCON
®
12.3 Uninstalling the AIO 2/AIO 4 assembly
1. Remove the 24V DC plug.
Figure199: Removing the plug (voltage supply)
2. Remove the plug.
Figure200: Removing the plug (analog inputs/outputs)
