MR TAPCON - Dimensions and Weight

15 Technical data
Maschinenfabrik Reinhausen GmbH 2020322 3587317/21 ENTAPCON
®
MC 2-2
+
-
24V DC
+
-
24V DC
ETH12 ETH22
ETH11 ETH21
93 mm (3.66 in)
ca. 150 mm (5.9 in)
119 mm (4.69 in)
54 mm (2.12 in)
Figure221: MC2-2 and SW3-3 dimensions
15.8 Dimensions and weight
Housing
W x H x D
19-inch plug-in housing in accordance with DIN41494
Part5
483mm x 133mm x 178mm (19in x 5.2in x 7in)
Weight Max. 7.9kg
