6 Mounting
Maschinenfabrik Reinhausen GmbH 2020 733587317/21 EN TAPCON
®
Connecting the voltage supply
To connect the voltage supply, proceed as follows:
► Connect the voltage supply in accordance with the connection diagram
provided.
6.7 Checking functional reliability
To ensure that the device is wired correctly, check its functionality.
NOTICE
Damage to device and system periphery
An incorrectly connected device can lead to damage to the device and sys-
tem periphery.
► Check the entire configuration before commissioning.
► Prior to commissioning, check the supply voltage and the measured volt-
age.
Check the following:
▪ Once you have connected the device to the grid, the display shows the
MR logo and then the operating screen.
▪ The voltage display LED on the top left of the device's front panel lights
up.
The device is fully mounted and can be configured. The actions required for
this are described in the following chapter.
