MR TAPCON - System Networking

15 Technical data
Maschinenfabrik Reinhausen GmbH 2020320 3587317/21 ENTAPCON
®
Optional accessories
CAN bus Terminating resistor
▪ D-SUB plug connector (9-pole)
▪ R = 120Ω
Connector with terminal strip for directly connecting CAN
lines
Media converter for
COM2 interface (only
RS232)
Adapter from D-SUB (9-pole) to fiber-optic cable:
▪ ACF660/ST: F-ST, 660nm, range max. 60m at 40kBd
▪ ACF660/SMA: F-SMA, 660nm, range max. 60m at
40kBd
▪ ACF850/ST: F-ST, 850nm, range max. 1,000m at
40kBd
▪ ACF850/SMA: F-SMA, 850nm, range max. 1,000m at
40kBd
Table143: Optional accessories
15.7 System networking
MC 2-2
Description Media converter
Interfaces 2x RJ45
2x duplex LC (SFP)
RJ45 Max. 100m (per section)
10/100 Mbit/s
Cable impedance 100Ω
Fiber-optic cable Max. 2,000 m
100 Mbit/s
Light-emitting diode: class 1
Wave length: 1310nm
Max. optical output power: <1 mW (in accordance
with IEC 60825-1:2014)
Table144: Technical data for the MC 2-2 assembly
SW 3-3
Description Managed fast Ethernet switch per IEEE802.3,
store-and-forward switching
Interfaces Media converters:
▪ 1x RJ45
▪ 1x duplex LC (SFP)
Managed switch with redundancy function:
▪ 2x RJ45
▪ 2x duplex LC (SFP)
Redundancy protocols PRP
1
, RSTP
