6.6.6 Wiring the CPU assembly
1. Connect the ETH 2.2 interface to a PC to access the web-based visualiza-
tion.
Figure45: Connection to a PC via Ethernet interface
2. Connect the ETH 1 interface to the control system (SCADA) in accor-
dance with the connection diagram.
Figure46: SCADA connection
Observe the information on connecting serial interfaces [►Section 6.6.2,
Page 58].
