8.20.2 Displaying measured value recorder (optional)
You can use the optional measured value recorder function to display the
progress of measured values and signals over time.
Depending on device configuration, you can select the following measured
values and signals for the display:
Signal Description
P_m L1 Active power L1 (average value)
P_m L2 Active power L2 (average value)
P_m L3 Active power L2 (average value)
P_m Active power in total (average value)
S_m L1 Apparent power L1 (average value)
S_m L2 Apparent power L2 (average value)
S_m L3 Apparent power L3 (average value)
S_m Apparent power in total (average value)
U_m Desired Desired voltage value (average value)
f_m Frequency (average value)
φ_m U1/I1 Phase angle U1/I1 (average value)
φ_m U2/I2 Phase angle U2/I2 (average value)
φ_m U3/I3 Phase angle U3/I3 (average value)
cos(φ_m) L1 Power factor L1 (average value)
cos(φ_m) L2 Power factor L2 (average value)
cos(φ_m) L3 Power factor L3 (average value)
cos(φ_m) Power factor in total (average value)
I_m N Neutral conductor current (average value)
I_m L1 Current L1 (average value)
I_m L2 Current L2 (average value)
I_m L3 Current L3 (average value)
U_m L1 Voltage L1 (average value)
U_m L2 Voltage L2 (average value)
U_m L3 Voltage L3 (average value)
Q_m L1 Reactive power L1 (average value)
Q_m L2 Reactive power L2 (average value)
Q_m L3 Reactive power L3 (average value)
Q_m Total reactive power (average value)
Auto block Auto mode blocked
HSR tap position ↓ High-speed return lower step
HSR tap position ↑ High-speed return raise step
