8 Operation
Maschinenfabrik Reinhausen GmbH 2020 2193587317/21 EN TAPCON
®
Signal Description
Req. HSR tap position
↓
High-speed return request lower step
Req. HSR tap position
↑
High-speed return request raise step
I>> Limit value I>> exceeded
U>> Limit value U>> exceeded
U Desired (prim.) Desired voltage value (on primary side)
U Desired Desired voltage value (on primary or secondary side, in ac-
cordance with configuration of measured value display pa-
rameter)
Tap position Tap position
P L1 Active power L1
P L2 Active power L2
P L3 Active power L2
P Active power in total
S L1 Apparent power L1
S L2 Apparent power L2
S L3 Apparent power L3
S Apparent power in total
f Frequency
φ U1/I1 Phase angle U1/I1
φ U2/I2 Phase angle U2/I2
φ U3/I3 Phase angle U3/I3
cos(φ) L1 Power factor L1
cos(φ) L2 Power factor L2
cos(φ) L3 Power factor L3
cos(φ) Power factor in total
I N Neutral conductor current
I L1 Current L1
I L2 Current L2
I L3 Current L3
U L1 Voltage L1
U L2 Voltage L2
U L3 Voltage L3
Q L1 Reactive power L1
Q L2 Reactive power L2
Q L3 Reactive power L3
Q Total reactive power
