12 Uninstallation
Maschinenfabrik Reinhausen GmbH 2020292 3587317/21 ENTAPCON
®
2. WARNING! Make sure that the current transformer is shorted. Other-
wise dangerously high voltages could occur. Remove the plug for the cur-
rent measurement.
Figure197: Current measurement
3. Loosen the fixing screws and unplug the assembly.
Figure198: Unplugging the UI assembly
